Terex Manlift Specifications
Based in Westport, Connecticut, Terex specializes in making construction machinery. They manufacture machinery such as aerial lifts, manlifts and boom lifts. These machinery are designed to facilitate access to areas which are difficult to reach, buildings and roofs, large equipment, among other things. A manlift, as defined by the U.S. Occupational Safety and Health Administration refers to a power-driven endless belt. This belt only moves in one direction and contains steps or handholds or paltforms which are attached to the unit to be able to move employees from each floor.
TB85
The TB85 man lift by Terex offers a max working height at 91 feet. The max height of the platform reaches 85 feet, whilst the model's maximum width is 8.5 feet. The TB85 has dimensions measuring 9 inches wide and 9 feet, 1-inch high by 36 feet. This model offers a reach of 70 feet. The TB85 has a boom angle above horizontal measuring 75 degrees and below horizontal measures at -14 degrees.
Terex TB100
The Terex TB100's maximum working height is 106 feet and the platform's maximum height is 100 feet. When the TB100 is stowed it is 8 feet, 1 1/2 inches wide by 9 feet high by 8 feet. The maximum width of the unit is 8 feet, 1 1/2 inches. The boom angle above horizontal is 75 degrees and below horizontal is 14 degrees. The horizontal reach measures at 67 feet, 4 inches.
TB110
The TB110 has a maximum platform height of 100 feet and the unit's maximum working height overall measures at 116 feet. When stowed, this model is 9 feet, 4 inches high x 8 feet wide. The TB110 offers a maximum width of 8 feet and a horizontal reach of 67 feet. This particular model has a boom angle of 75 degrees above horizontal plus 10 degrees articulating. It measures -105 degrees articulating and below horizontal it is -14 degrees.
